TDR347S
Grey Resin Ribbon
TDR347S is a grey resin ribbon with good scratch and corrosion resistance. It's mainly used in semi-high gloss and high gloss black label scenarios such as consumer electronics and batteries.
-
Excellent Scratch Resistance
-
Nice Corrosion Resistance
-
Outstanding Printing Quality
Print Quality
-
Blackness0.5 2.5
1.4 ODR -
Sharpness0 100
93 -
0° Barcode0 100
100 -
90° Barcode0 100
90 -
Min. printable character0 6
3 pt -
Graphics0 100
100
Printability
-
Uncoated paperWriting paper, Vellum…
-
Coated paperArt Paper, Art Printing Paper, High Gloss Paper…
-
Synthetic paperSynthetic paper
-
Film labelPP/PET/PE/PVC…
Sensitivity
-
Print Speed
-
Printing Speed
Durability Test
Physical Resistance
Slight exposure begins after approx, X cycles with a 680G weight load
-
Braking FluidBosch Dot4 Plus
-
Gasoline92#
-
Alcohol95%
-
Stratch Resistance
-
Rub resistance
- 20
- 10
- 70
- 400
- 500
- 600 100 50
- 50 100 600 次
-
Water resistance testThe printed label was soaked inwater at 100℃ for 2 hours and then check whether the imprint of thelabel was significantly faded.
-
No significantly faded
-
Low-temperature testThe printed label was placed in a closed cold box at -17°C for 20 hoursand then check whether the imprint of the label was significantly fallen off.
-
No significantly fallen off
-
Certification and Permits
ROHS2.0
REACH
MSDS
Halogen Free -
Same Series Products
Recommended Application Scenarios
-
Household & Personal Care Lebel
-
Home Appliances
-
Electronic Component Identification
-
Product Nameplate
-
PropertiesPET FilmThickness: 4.5μmRibbonThickness: 7.5±0.3μmInk90±3℃Storage ConditionTemperature: 5~35℃, Humidity: 20~80%, Validity Period: 12 months
-
Product Comparison
-
TDR347S
-
Substrate CompatibilityDurability
-
